6mm Thick, Clean Float Glass Manufacturing Machinery and Equipement

1. Brief Description

The name of float glass is because of the glass liquid floating and forming on a metallic tin liquid surface. By using this forming method, it is not need to overcome the gravity of the glass, it can enlarge the width of the glass, improve the speed of stretch, and increase the capacity and scale of production.

The production technology of float glass is the largest scale mechanization and automation methods of production of flat glass production technology at present time.

2. Thickness and Application

3. Scope ofSupply

• Raw material treatment system
• Internal and external cullet system
• Glass furnace
• Tin bath
• Cold end device
• Utlity equipemnt
• Auto control system

4. Raw Materials

Main materials are mainly including:

5. Technical Flow Chart of Float Glass Line

• Qualified batching materials transfer to the furnace for melting.
• Melted glass liquid flows onto tin bath and form a glass plate through mechanical and chemical methods.
• When the temperature of glass plate reduced around 600°C, it will conveyor into annealing lehr and relief the stress.
• After inspection and cutting, the yield glass product conveyors to packing area.

6. Main Equipment Description

6.1 Batch Plant

For batching and mixing the raw materials.

6.2 Furnace

The melting tank is key part of glass production line, the refractory materials quality is very important.

6.3​ Tin Bath

It is a key and one of most important equipment of float glass production line. Glass liquid float on the metallic tin, through stretching, forming, polishing and cooling processing, a qualified glass plate is formed and its temperature reduces around 600°C, the transition roller will send the plate to annealing lehr.

6.4.Protection Gas Station

The protection gas station shall operate continuously to produce and supply the required gas for tin bath.

Tin is easy to reaction with oxygen, sulfur under high temperature and form an oxide, its oxide (SnO2, SnO) will seriously pollute the glass liquid, this will affect the quality of the glass.

6.5. Annealing Lehr

In glass technology, annealing means to put the glass into the annealing lehr for a certain time or reduce the temperature with a slow speed, so as to no additional permanent stress or temporary stress will produce. Namely, annealing also means a process which will reduce or eliminate the thermal stress of glass.

6.6. Colde-end

• Inspection and pretreatment section
• Cutting and break section
• Stacker and packing section

JEFFER ENGINEERING, a China professional company that designs and provides complete glass melting technology as a global solution partner for the glass industry. With overseas subsidiaries in Russia, Egypt and Indonesia, JEFFER has met its demand for rapid local activity of the glass industry's requirement.

With its more than 40 years of experience in glass melting, JEFFER has combined conventional furnace technology with new furnace concepts in modern days, it has a wide range of experience in the design, manufacture and supply of different furnace types for production of Container Glass, Tableware Glass, Flat Glass, Figure Glass, Tube Glass, Opal Glass, Fiber Glass, Sodium Silicate, Frit etc.

We put the interests of our customers first and maintain close ties through high quality work and good after sale cooperation. Many long-term relationships with our customers span several decades.

The range of products and service does not only include melting tank, JEFFER also fabricates the main utility equipment such as providing combustion system and automatic instrument. Furthermore, with our staff, JEFFER can meet the requirements of the glass industry, such as Feasibility Studies, Plant Design, Material and Equipment Supply, Commissioning and Start-Up, Construction Supervision, Contract Management and Implementation, Plant Renovation, Global Consulting Services for Plant Operation.

With 24/7 hotline service, our service staff can respond quickly to help with any problems that may arise during the glass production process.

With customer's trust and praise, we are worthy of our reputation.
